Product description

• Independent driver with strain-relief housing

• Extra flat housing for constrained installation conditions (small ceiling cut outs and low ceiling voids)

• For luminaires of protection class I and protection class II

• Temperature protection as per EN 61347-2-13 C5e

• Output current 250 mA

• Nominal lifetime up to 50,000 h

• 5 years guarantee (conditions at https://www.tridonic.com/manufacturer-guarantee-conditions)

Housing properties

• Casing: polycarbonate, white

• Type of protection IP20

• Push-in terminals

• 2 separate strain relief parts for input and output cables with highly robust clamps

Functions

• Overload protection

• Short-circuit protection

• No-load protection

• No output current overshoot at mains on/off

• Burst protection voltage 1 kV

• Burst protection voltage 1 kV (L to N)

• Surge protection voltage 2 kV (L/N to earth)

Typical applications

• For spot light and downlight in retail and hospitality applications

• For panel light and area light in office and education application

EAN/UPC: 9006210736211
